DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
304 Web-Based Switch Management
LSDB Type Displays which one of four types of link
advertisements by which the current link
was discovered by the switch − Router
link (RTRLink), Network link (NETLink),
Summary link (Summary), Autonomous
System link (ASSummary).
Adv Router ID Displays the Advertising Router’s ID.
Link State ID This field identifies the portion of the
internet environment that is being
described by the advertisement. The
contents of this field depend on the
advertisement's LS type.
LS Type Link State ID
_________________________________________
5
The destination network’s IP
address.
Mask Displays the network mask in
hexadecimal format. For example,
255.0.0.0 is displayed as FF000000.
Cost Displays the routing metric associated
with the link.
Sequence Displays a sequence number
corresponding to number of times the
current link has been advertised as
changed.
