DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
230 Web-Based Switch Management
MD5 Key Table Configuration
menu. When MD5 is selected, the
Auth Key ID:[ ] field allows the
specification of the Key ID as defined
in the MD5 configuration above.
This must be the same MD5 Key as
used by the neighboring router.
Metric This field allows the entry of a
number between 1 and 65,535 that
is representative of the OSPF cost of
reaching the selected OSPF interface.
The default metric is 1.
OSPF Interface Configuration − Monitor
To view the current configuration of any OSPF Interface
on the switch, click the corresponding Interface’s click-
box and then click the Monitor button to open the
following dialog box:
