DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
226 Web-Based Switch Management
Figure 6-37. OSPF Area Setting
The following fields can be set or are displayed:
Parameter Description
Area ID A 32-bit number in the form of an IP
address (xxx.xxx.xxx.xxx) that
uniquely identifies the OSPF area in
the OSPF domain.
Type This field can be toggled between
Normal and Stub using the space
bar. When it is toggled to Stub,
additional fields appear − Stub
Import Summary LSA, and Stub
Default Cost.
Stub Import
Summary LSA
Displays whether or not the selected
Area will allow Summary Link-State
Advertisements (Summary LSAs) to
be imported into the area from other
areas.
Stub Default Cost Displays the default cost for the
route to the stub of between 0 and
