D-Link DES-3326S - Manual (Page 166)

DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
166 Switch Management and Operating Concepts
metric.
Forwarding Address Data traffic for the
advertised destination will
be forwarded to this
address. If the
Forwarding Address is set
to 0.0.0.0, data traffic will
be forwarded instead to
the advertisement’s
originator.
TOS The Type of Service that
the following cost is
relevant to.
Metric The cost of this route.
The interpretation of this
metric depends on the
external type indication
(the E – bit above).
External Route Tag A 32-bit field attached to
each external route. This
is not used by the OSPF
protocol itself.
Table 5-25. AS External System Advertisement
