DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
210 Web-Based Switch Management
To edit an existing 802.1Q VLAN, click the corresponding
click-box and then click the Edit icon to open the
following dialog box:
Figure 6-26. 802.1Q Static VLANs Entry Settings – Edit
The following fields can then be set in either the Add or Edit
dialog boxes:
Parameter Description
VLAN ID (VID) Allows the entry of a VLAN ID in the
Add dialog box, or displays the VLAN
ID of an existing VLAN in the Edit
dialog box. VLANs can be identified
by either the VID or the VLAN name.
The Auto Assign click box will
instruct the switch to assign VLAN
IDs − in ascending numerical order
starting with 1 − to each VLAN as it
is created.
