DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
224 Web-Based Switch Management
Setup OSPF
The OSPF General Setup dialog box allows OSPF to be enabled
or disabled on the switch − without changing the switch’s OSPF
configuration. In addition, the switch can be designated as an
Autonomous System (AS) Border Router or not.
From the Layer 3 IP Networking folder, click on the OSPF
folder and then click on the General link:
Figure 6-36. Setup OSPF
The following parameters can be set or are displayed:
Parameter Description
OSPF Route ID A 32-bit number (in the same format
as an IP address − xxx.xxx.xxx.xxx)
that uniquely identifies the switch in
the OSPF domain. It is common to
assign the highest IP address
assigned to the switch (router). In
