DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
238 Web-Based Switch Management
IGMP Snooping, DVMRP, and PIM-DM routing protocols can
be individually enabled or disabled, globally on the switch −
without changing the individual protocol’s configuration from
the above window.
IGMP Snooping Settings
To configure IGMP Snooping:
From the Layer 3 IP Networking folder, select the IP
Multicast Routing Protocols folder, and click IGMP Snooping
Configurations to open the following dialog box:
Figure 6-45. IGMP Control Setup
The following fields can be set:
Parameter Description
VID Allows the entry of the VLAN ID (VID)
for which IGMP Snooping is to be
configured.
State <Disabled> This field can be switched using the
pull-down menu between Disabled
