DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
216
Web-Based Switch Management
Using a 10.xxx.xxx.xxx IP address notation, the above example
would give 6 network addresses and 6 subnets.
Any IP address from the allowed range of IP addresses for each
subnet can be chosen as an IP address for an IP interface on
the switch.
For this example, we have chosen the next IP address above
the network address for the IP interface’s IP Address:
VLAN Name
VID
Network Number
IP Address
System (default)
1
10.32.0.0
10.32.0.1
Engineer 2
10.64.0.0 10.64.0.1
Marketing 3
10.96.0.0 10.96.0.1
Finance 4
10.128.0.0
10.128.0.1
Sales 5
10.160.0.0
10.160.0.1
Backbone 6
10.192.0.0 10.192.0.1
Table 6-4. VLAN Example – Assigned IP Interfaces
The 6 IP interfaces, each with an IP address (listed in the table
above), and a subnet mask of 255.224.0.0 can be entered into
the Setup IP Interface window.
To setup IP Interfaces on the switch:
Go to the Advanced Setup folder, and click on the Layer 3 IP
Networking link, and then click on the Setup IP Interfaces
link to open the following dialog box:
