DES-3326S Layer 3 Fast Ethernet Switch User’s Guide
Web-Based Switch Management 235
Figure 6-43. Route Redistribution Settings
The following fields can be set or are displayed:
Parameter Description
Source Protocol Allows the selection of the protocol of
the source device. Available choices
are RIP, OSPF, or Static.
Destination
Protocol
Allows the selection of the protocol of
the destination device. Available
choices are RIP and OSPF.
Metric Type Allows the selection of one of two
methods for calculating the metric
value. Type-1 calculates the metric
(for RIP to OSPF) by adding the
destination’s interface cost to the
metric entered in the Metric field.
Type-2 uses the metric entered in the
Metric field without change. This
field applies only when the
destination field is OSPF.
Metric Allows the entry of an OSPF interface
cost. This is analogous to a Hop
