t_jei;aMed Setup
\
Keystoning
Tlie normal projected image will have a rectangular shape.
Keystoning is when the projecrcci image becomes trapezoidal.
800
800
400
200
0
Mil
Mm
I KAY i juM m
Norme) Image
Keyscooed Image
Fj
0
Mr-® ea
fStorme
‘tTssI vs. keysconecJ images
Keystoning occurs when the front of the Desktop Projector is not
perpendicular to the projection screen (the vertical plane) or when
it’s not placed parallel to the floor (the horizontal plane}.
Keystoning also occurs when the Desktop Projector is tilted
sidew^ays.
•
User's Guide
