6
Chapter 6
Interfaces
40
Pin No.
Signal Name
Direction
Function
When this signal goes “Low,” the printer becomes
BUSY. It is initialized after all the data are printed.
31
*INIT
IN
BUSY is not cleared until this signal goes “High.”
A pulse width of 1
µ
sec or longer is required at the
receiving end.
(See “When Receiving the INIT Signal.”)
32
*FAULT
OUT
This signal indicates that the printer is in the error state.
It goes “Low” under any one of the following condi-
tions.
• Paper End
• When an abnormal operation is detected.
33
GND
Signal line ground.
34
DRAWER
KICK
OUT
The drawer kick connector's status signal is output.
STATUS
35
FUSE
OUT
Connected to +5 V through a 3.3k ohm resistor.
36
Not used.
•
IN indicates signals from the Host to the printer, and OUT indicates signals from the
printer to the Host.
* means negative logic signals.
