Automatic Computer Controlled Thread Metering (tension) System
Instead of a mechanical tension system, which controls thread by squeezing it between 2 discs, the XL-1000 controls
thread by computer. An automatic computer controlled thread metering system delivers the precise amount of thread
for each needle penetration to create the optimal appearance of each stitch. This makes possible, perfectly balanced
straight stitch, plus no pucker blind hemming, two color patterns without changing thread, multicolored embroidery
without changing bobbin thread, and decorative top-stitching and cross stitching that simulate hand sewn. An override
control allows individual modification for specialized effects.
Examples of Automatic Thread Metering:
Upper thread
Upper thread
Upper thread
nrnr
Bobbin thread Fabric
(Wrong side)
Fabric (Right side)
y^teil3|
Bobbin thread
Embroidery and decorative topstitch Two-color patterns: Upper and
patterns: Upper and bobbin thread bobbin thread join on right side
join on wrong side of fabric to
of fabric,
optimize top side appearance.
Straight stitch: Upper and bobbin
thread join in middle.
How to modify top thread supply.
Use thread meter override touch-screen
to modify top thread supply (tension).
©□
g---------------
■
CD
1
A
1
1
i
1
10
1
20
f XX ^
GOBDD
_____________ y
qdédb
I
CUD
y
Indicates that thread
metering (tension) is
automatic.
■QDBDE)
am©
Press to decrease
top thread supply
(increase tension).
0
;
A-B-C
NOTE: With decorative patterns the thread meter
(tension) override touch-screen does not
appear automatically. To make touch-screen
appear, first select pattern. Second press
E
53
^ pop-up screen with the touch-screen
will appear. Adjust as above.
How to shirr and gather.
When shirring an armhole or skirt waist, or gathering
cuffs or yokes, sew with a long thread length, then pull
bobbin thread by hand to gather material.
Set stitch length to 3 « U~4 « 0-
EEHII
Increase top thread supply.
XDC
Press (2 to Increase
top thread supply
(decrease tension).
22
