66

SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide

Installation

SmartStack STS-LM Connectors and LEDs

The following tables describe the connectors and LEDs on the STS-LM front
panel.

Connecting the Stacker Link Cable

When connecting two or more stacker link modules together to form a stack, you
must use the proprietary 50-pin cable supplied with the module.

The SmartStack STS16-20D/STS16-20R switch can be configured in three
different ways to form a stack of switches:

Two of the SmartStack STS16-20RM family switches back-to-back via two
SmartStack STS-LM modules

Up to five SmartStack STS16-20RM family Switches via one SmartStack
STS-5SU Stack Link Module and up to four SmartStack STS-LM Modules.

Up to eight SmartStack STS16-20RM family Switches via one SmartStack
STS-8SU Stacker Unit and up to eight SmartStack STS-LM Modules.

When inserting the cable connector, keep the connector straight to minimize the
risk of bent or damaged pins.

Note:

Stacked SmartStack STS16-20RM family switches must all have the same

software version.

Connector

Description

Stacker Port

50-pin SCSI-2 connector for proprietary
Stacker Link cable.

Table 10. SmartStack STS-LM Network Connector

LED

State

Description

TX

On

Data is being transmitted from the
attached switch.

RX

On

Data is being received by the
attached switch.

ATTACH

Off

No connection has been established.

On

A connection has been established.

Table 11. SmartStack STS-LM LEDs
