199
Monitoring the Network from the Console Statistics Menu SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
Display Summary Screen
To open this screen from the main menu, select Statistics
→ → → →
Display Summary.
This screen gives access to the most important switch configuration parameters in
a summary form. The information is suitable for saving to an ASCII file by means
of a capture function in the terminal emulation program used. This file will often
be requested by the Cabletron Systems technical support personnel in case of
troubleshooting:
SPACE
Pressing the SPACE key, you will start a screen report of all entered parameters,
which runs through the display, until you stop it, or the bottom is reached. Press any
key to return to the menu.
ESC
Pressing ESC , you cancel and return to previous menu.
❏
