191
Monitoring the Network from the Console Statistics Menu SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
VLAN Statistics
If you select VLAN Statistics, you will be prompted for a VLAN type. On selection
of the VLAN type, a screen will be displayed listing available VLANs and
prompting for a selection. Following your selection, the CRF or BRF VLAN
Statistics
screen will be displayed.
VLAN Statistics Screen for CRF
To open the VLAN Statistics screen for CRF, do the following:
1. From the main menu, select Statistics
→ → → →
VLAN Statistics .
2. You will be prompted for a VLAN type. Select CRF.
3. Select a CRF. The VLAN Statistics screen for CRF appears.
Parent VLAN
The parent BRF.
Currently Active Stations
Number of MAC addresses currently in the master address table that are recognized
as belonging to this CRF.
Largest Number of Stations
Largest number of MAC addresses in the master address table—since the last reset
or power cycle—that are recognized as belonging to this CRF.
