35
Switch Overview SmartStack STS16-20D/STS16-20R Token Ring Switches Installation and User Guide
Management
This section describes the management options for the switch.
SNMP
The SmartStack STS16-20D/STS16-20R can be managed via a SNMP manager.
The SmartStack STS16-20D/STS16-20R supports ten Management Information
Bases (MIBs). Six of the MIBs are standard MIBs, which are defined by RFCs and
are included with most SNMP management applications. Four of the MIBs are
proprietary and are provided on the disk that accompanies the SmartStack STS16-
20D/STS16-20R. SNMP management is supported via IP and MAC.
The following MIBs are supported:
Most user configurable variables will be supported in either the standard MIBs or
the proprietary MIB. Configuration settings, such as port attributes, and operational
information, such as address tables, are fully accessible through SNMP. Certain
other settings, such as passwords and console settings, cannot be viewed or
modified via SNMP for security reasons.
Specification MIB
RFC1213 MIB II
RFC1493 Bridge MIB
RFC1525 SR Bridge MIB
RFC1573 Evolution of the Interfaces Group of MIB-II
RFC1757/1513 RMON MIB/TR extensions - Only partial support
RFC1749/1748 IEEE 802.5 MIB
DTR MIB IEEE 802.5r MIB
DTR MAC MIB IEEE 802.5r MIB
STS16 MIB 1.3.6.1.4.1.52.285
STS16 MIB 1.3.6.1.4.1.9 (crosslinks)
Table 8. Supported MIBs
