SmartSwitch Router User Reference Manual 325
Chapter 22: WAN Configuration Guide
Monitoring Frame Relay WAN Ports
Once you have configured your frame relay WAN interface(s), you can use the CLI to
monitor status and statistics for your WAN ports. The following table describes the
monitoring commands for WAN interfaces, designed to be used in Enable mode:
Frame Relay Port Configuration
To configure frame relay WAN ports, you must first define the type and location of the
WAN interface, optionally “set up” a library of configuration settings, then apply those
settings to the desired interface(s). The following examples are designed to give you a
small model of the steps necessary for a typical frame relay WAN interface specification.
To define the location and identity of a serial frame relay WAN port located at slot 5,
port 1 with a speed rating of 45 million bits per second:
To define the location and identity of a High-Speed Serial Interface (HSSI) VC located at
slot 4, port 1 with a DLC of 100:
Suppose you wish to set up a service profile called “profile1” that includes the following
characteristics:
• Committed burst value of 2 million and excessive burst value of 1 million
• BECN active shaping at 65 frames
Display a particular frame relay
service profile frame-relay show service
Display all available frame relay
service profiles frame-relay show service all
Display the last reported frame
relay error frame-relay show stats port
last-error
Display active frame relay LMI
parameters frame-relay show stats port
lmi
Display MIBII statistics for frame
relay WAN ports frame-relay show stats port
mibII
Display a summary of all LMI
statistics frame-relay show stats port
summary
ssr(config)# port set se.5.1 wan-encapsulation frame-relay speed
45000000
ssr(config)# frame-relay create vc hs.4.1.100
