APPENDIX A: TERMINAL CORRESPONDENCE
The terminals of an VT8600 are identified differently and have a wider range of possible functions compared to those of any of the
VT7000 series Room Controllers. Nonetheless, there is a direct correspondence of functions between the terminals of the VT7000
series and the VT8600 series. Consult the table below to verify the appropriate terminal when replacing a VT7000 Room Controller
with a VT8600 Room Controller.
VT7000 VT8600
Terminal name Terminal ID Terminal name Terminal ID
Binary Input 1 BI1 Universal Input 16 UI16
Binary Input 2 BI2 Universal Input 17 UI17
Universal Input 3 UI3 Universal Input 19 UI19
Sensor Common Scom Terminal 18 Common COM
Remote Sensor RS Universal Input 20 UI20 - RS
Sensor Common Scom Terminal 21 Common COM
Mix/Supply Sensor MS Universal Input 22 UI22 - SS
