VT8600 Series

25

User Interface Guide

© 2

01

4 V

ic

on

ic

s T

ec

hn

ol

og

ie

s. A

ll r

ig

ht

s r

es

er

ve

d

.

Viconics Technologies Inc.

9245 Langelier Blvd. Saint-Leonard, Quebec, Canada, H1P 3K9 I +1 514 321 5660

028-0441-00

www.viconics.com

November 2014

7/9 Configuration

Min fresh air

Econo. min pos. 0 %

Max CO2

Min CO2

Max fresh air

100 %

800 ppm

0 l/s

Econo. max pos.

0 l/s

1200 ppm

CONFIGURATION PARAMETERS SCREEN 7/9

PARAMETER DETAILS SCREEN 7/9

Configuration Parameters Default Value

Significance and Adjustments

Econo. min pos.
Minimum Fresh Air Damper/Economizer Position
Default value

: 0%

Minimum fresh air damper position. Effective only in Occupied mode
(Fan is ON). This value is also used to determine the fresh air damper
position based on the Min/Max CO2 and Min/Max Pos values set.
See Fresh Air Damper Position section for more details.
0% to 100%, 1 or 10 increments

Econo. max pos.
Maximum Fresh Air Damper/Economizer Position
Default value:

100%

Maximum fresh air damper position. Effective only in Occupied mode
(Fan is ON). This value is used to determine the fresh air damper
position based on the Min/Max CO2 and Min/Max Pos values set.
See Fresh Air Damper Position section for more details.
0% to 100%, 1 or 10 increments

Min fresh air
Minimum Fresh Air Value
Default value:

0 CFM

Minimum fresh air required. Effective only in Occupied mode (Fan is
ON). This value is used to determine the fresh air damper position
based on the Min/Max CO2 and Min/Max FA values (if FA Range is
set to other than 0 CFM). See Fresh Air Damper Position section for
more details.
0 to 20 000 CFM (0 to 9438 l/s, the value set cannot exceed
the value of FA Range parameter), 10 or 100 increments

Max fresh air
Maximum Fresh Air Value
Default value:

0 CFM

Maximum fresh air allowed. Effective only in Occupied mode (Fan is
ON). This value is used to determine the fresh air damper position
based on the Min/Max CO2 and Min/Max FA values set (if FA Range
is set to other than 0 CFM). See Fresh Air Damper Position section
for more details.
0 to 20 000 CFM (0 to 9438 l/s, the value set cannot exceed
the value of FA Range parameter), 10 or 100 increments
