TD-2300A Series V1.0 49
Product specification
Sensor Specifications
Frequency 433.92MHz
Pressure range 0-180 PSI
Accuracy Pressure ±3 PSI Temp ±2 Degrees Celsius
Operating voltage 3 Volts DC (Lithium CR1632 3V)
Operating temperature -40~125 Degrees Celsius
Operating humidity 100%
Battery life 6 or up to 12 Months (Depending on operation time)
Dimensions 20.5mm Diameter X 20mm Height
Weight 10 g (±1)
Relay Specifications
Frequency 433.92MHz
Operating Voltage 12V DC / 24V DC
Operating temperature -40~85 Degrees Celsius
Operating humidity 100%
Dimensions 105mm (L) X 50mm (W) X 85mm (H)
Weight 200g
Battery life 6 or up to 12 Months (Depending on operation time)
Specifications are correct at time of publication. Subject to change without notice.
