TD-2300A Series V1.0 20
Installation - Sensors Continued..
Visually inspect your tyre’s valves for any damage or defects before fitting
the sensors to ensure that further damage doesn’t occur. If you do notice
that something is not right with your valves, have them checked by a tyre
professional.
INSTALLATION
1. After removing the original valve caps, slide the SecureFit fixing ring
over the valve stem with the flat surface towards the wheel.
2. Screw the Tyredog sensor on in a clockwise direction until you feel the
valve stem come under pressure.
3. Slide the SecureFit fixing ring back up to the base of the sensor and
line up the grooves. Once locked into place, tighten the hex screw with
the supplied Allen key. (Don’t over tighten otherwise you might damage
your valve stem)
If you do not wish to use the SecureFit fixing ring, only follow step 2.
1.
2.
3.
