TD-2300A Series V1.0 24
TPMS Settings Menu
To access the Main Settings Menu, press and hold the Mute Button for 3
seconds or until the Menu Screen appears.
From this Menu you can access the following settings:
MAIN MENU OPTIONS
A) Unit Setting - Pressure (PSI/KPA/BAR/KgCm) - Temperature (°C / °F).
B) Threshold of Alarm - Set Low & High Pressure / High Temperature.
C) Type of Vehicle - Set Wheel Layout for each Relay.
D) Add new Relay (Reset/Synch Relay) - Program New or Reset Relay/s.
E) Add new Sensor - Program replacement LEARNABLE Sensors.
Settings
Mute Temperature Backlight
Settings Menu
>>
(Next)
ESC
(Escape) (Select)
A) Unit Setting
>>
(Change)
B) Threshold of
Alarm
+
(Increase)
-
(Decrease)
ESC
(Escape)
C) Type of
Vehicle
D) Add new
Relay
E) Add new
Sensor
(Enter/Save) (Next Option)
(Next Option)
(Next) (Previous) (Enter/Save)
(Select Relay)
N/A
ESC
(Escape)
N/A N/A
