TD-2300A Series V1.0 9
Relay description
Monitor bracket description
3-way adapter description
Top Bottom
Monitor Bracket
Sync Button
DC Socket
LED
(The 3-way adapter is not included. Please purchase it separately. )
Mounting holes
Battery cover
Antenna
Set screw
Monitor holder
Fixed lock ring
Suction cup control arm
Bracket stand
Holder arm base
Connection to valve
Hex socket set screw
Connection to Sensor
Inflation valve
