Chapter 1 - Introduction
4
Installation - Guidance
Avoid mounting the antenna close to other electrical instal-
lations (air conditioning equipment, radio antennas, etc.).
Avoid coiling excess antenna cable - configure it in a “fig-
ure 8” shape and keep the cable at least 1.5 feet (45.72
cm) from possible sources of electrical interference.
system Configuration
GPS Antenna
Position the GPS antenna in the center of the vehicle at
the highest point with a clear view of the sky. If the tractor
cab is non-metallic, mount the metal plate in the center of
the vehicle at the highest point with the Velcro
TM
strips and
place the antenna on the plate. Route the antenna cable
carefully to avoid damage and possible electrical interfer-
ence.
Metal plate
Antenna
GPS Speed Output
401-0016 Optional
Power Cable
External GPS Receiver Input/
Output
GGA 5 Hz
VTG 5 Hz
19200 Baud rate
C
a
u
t
Io
n
+
12
V
o
n
LY
W
a
r
n
In
G
C
o
n
n
e
C
t
d
Ir
e
C
t
LY
t
o
B
a
t
.
p
ow
er
C
ab
le
40
1-
00
16
d
C
:x
x/x
x
Rate
Controller
Harness
SmartCable
Adapter
Harness
45-05573
TeeJet 844-E
Rate Controller
Valves
Console
Power
Metal Mounting Plate
65-05179
Speed Cable
CAN
78-08057
Optional Tilt Gyro Module
TeeJet
CAN
GPS Antenna
RS-232
Remote Swath
Status Switch
(Optional)
Battery
60-10081 Velcro
TM
Metal Mounting Plate
65-05179
60-10081 Velcro
TM
