TeeJet CenterLine 230BP - Manual (Page 22)

CenterLine 230BP
98-05112 R4
21
all booms on mode
The CenterLine 230BP provides the option of turning all
booms on at the same time, regardless of vehicle position
or guidance mode. To turn all booms on, while the vehicle
is moving, press and hold the Swath Status Switch key
until All On Mode is illuminated on the console. Release
the Swath Status Switch key to turn off the booms.
a+ nudge feature
The A+ Nudge feature allows the existing A-B guideline to
be shifted to the vehicle’s current location. Press the Mark
A-B key immediately followed by pressing the Plus
key.
Pressing the Minus key after pressing the Plus key
will abort the nudge feature and the guideline will remain
the same.
aLL on
auto
Man
