JOB PARAMETERS
Job Parameters configures application settings. Options include Active Trip Counter and Preset Application Rates.
MAIN SETUP MODE MENU STRUCTURE
| | | | | |
Counters Job Parameters Machine User Interface Communication Help
Figure 3-12: Job Parameters
1. From the Main Setup Screen , select JOB
PARAMETERS.
NOTE: Settings are NOT automatically saved when
selected. The ACCEPT KEY must be selected
to save the setting. Select the ESCAPE KEY
to escape without saving settings and return to the
previous menu.
Active Trip Counter
Active Trip Counter selects one of up to ten (10) active trip
counters to view the desired trip information. The trip that
is “active” is displayed/active on the Operation Screen.
• To select the Active Trip Counter, use the number
pad or slide bar.
NOTE: The selected trip counter will have all data modified (added too) when additional operations are activated.
If current trip counter is not cleared, the new data will be added to the existing data.
Preset Application Rates
Preset Application Rates define up to five (5) target rates of product being applied per hectare/acre. These
settings will set the same for all active trips. Target rates set to "0.0" will not be in included in the TOGGLE
PRESET TARGET RATE options on the Operation Screen or Home Screen.
• To select the Application Rate, use the number pad or slide bar.
