Master Screen
The Master Screen gives access to the systems currently available on your VT.
• To view the Master Screen options, select MASTER SCREEN KEY in bottom right corner of any
screen.
Figure 3-2: Master Screen Master Screen Key on Main Setup Screen
Home Screen
The Home Screen gives access to the IC18’s available functions: Operation Mode, Transport Mode and
Main Setup.
• To view the Home Screen, select HOME KEY in the top right corner of any screen.
Figure 3-3: Home Screen Home Key on Main Setup Screen
