ISOBUS Job Computer : IC18 Sprayer
Calibrations
Implement Speed Sensor
Description Factory Setting Range/Options User Setting
Pulses per Distance 0 0 - 33445
Alarm Configurations
Description Factory Setting Range/Options User Setting
CAN Speed Source Timeout 4 sec 0 - 999
Active Trip Count Imformtaion Off Off
On
Tank Content Minimum 0 GAL (US)
0 liters
0 GAL (UK) 0 - 2641 (US)
0 - 9999
0 - 2199 (UK)
USER INTERFACE
Description Factory Setting Range/Options User Setting
Use Perferred VT Off Off
On
Pair with Switchbox Auto Auto
None
<>
Pair with BoomPilot ECU Auto Auto
None
<>
Show Number on Soft Key No No
Yes
Sprayer Number (FI) 1 1 - 9
APPENDIX B - UNIT SPECIFICATIONS
Dimensions 19.05 x 18.42 x 6.03 cm
Weight 0.644kg
Connector 30 position Cinch pins. A1-K3
30 position Cinch pins. L1-Y3
Environmental Operating -40 to +85°C
Humidity 90% non-condensing
Input/Output ISO 11783 (ISOBUS)
Power Requirement <9 watts @12 VDC
