ISOBUS Job Computer : IC18 Sprayer
Trip Counters
Figure 3-5: Trip Counters Menu
Figure 3-6: Confirm Counter Clearance
Figure 3-7: Campaign Counters
Figure 3-8: Confirm Campaign Clearance
Trip Counters displays information regarding area, distance, time and amount
applied. The trip that is active is displayed/active on the Operations Screen.
Active Trip Counter
One of up to ten (10) Active Trip Counters can be selected to view the desired trip
information. The trip that is “active” is displayed/active on the Operation Screen.
• To select the Active Trip Counter, use the number pad or slide bar.
• To clear the Trip Counters, select TRASH CAN KEY . A confirmation
screen will be displayed.
Area Counter
Displays applied coverage area for the selected Active Trip.
Distance Counter
Displays distance traveled for the selected Active Trip.
Time Counter
Displays time traveled for the selected Active Trip.
Volume Counter
Displays volume of material applied during the selected Active Trip.
Campaign Counters
Campaign Counters display information regarding area, amount applied and time
for all trips.
• To clear the Campaign Counters, select TRASH CAN KEY . A confirmation
screen will be displayed.
Area Counter
Displays total applied coverage area for all trips.
Volume Counter
Displays total volume of material applied during all trips.
Time Counter
Displays total time traveled for all trips
