Parameter Mapping
All 16-bit values are in Big Endian format. For example, the value 23 would be presented as 0 in the first channel and
23 in the second channel.
Start
Size
Type
Universe
1 4 Ambient
Light
1st
466 Total
Channels
5 4 Spot
Light
1
9 4 Spot
Light
2
13 4 Spot
Light
3
17 4 Spot
Light
4
21 32 Master
Control
53 20 Shutter
Control
73 22
Keystone
Control
95 62
Layer
1
157 62
Layer
2
219 62
Layer
3
281 62
Layer
4
343 62
Layer
5
405 62
Layer
6
1
62
Layer 7
2nd
372 Total
Channels
63
62
Layer 8
125
62
Layer 9
187
62
Layer 10
249
62
Layer 11
311
62
Layer 12
