DMX Layer Volume Control
When using DMX Layer Volume control, the layers don't
have to be controlled by the same universe, or using
consecutive addresses.
Chan
Size
Function
Default
Snap
1
1
Layer 1 volume
255
N
2
1
Layer 2 volume
255
N
3
1
Layer 3 volume
255
N
4
1
Layer 4 volume
255
N
5
1
Layer 5 volume
255
N
6
1
Layer 6 volume
255
N
7
1
Layer 7 volume
255
N
8
1
Layer 8 volume
255
N
9
1
Layer 9 volume
255
N
10
1
Layer 10 volume
255
N
11
1
Layer 11 volume
255
N
12
1
Layer 12 volume
255
N
Draw Mode
Values
Mode
Description
0 NONE
no
effect
1 Light/Trim
automatic ambient lighting of
object/trims edge of backgrounds
2
Cut
cuts holes in stencil mask
3
Cut + Light
as above w/ lighting
4
Cut & Draw
as mode 2 but texture is drawn on
object too
5
Cut & Draw +
Light
as above w/ lighting
6
Draw thru
Stencil
this layer's texture is drawn where
holes have been cut in stencil
7
Draw thru
Stencil + Light
as above w/ lighting
8
Draw onto
Stencil
this layer's texture is drawn where
stencil is not cut
9
Draw onto
Stencil + Light
as above w/ lighting
16
Orthographic
Projection
shows 3D object in ortho mode
32
Additive
layer’s colors are added to
underlying colors (blacks appear
transparent)
64
Screen
similar to above, with less of
underlying color (blacks appear
transparent)
96
Multiply
multiplies layer’s color with
underlying color (blacks appear
opaque)
128
Subtractive
layer’s colors are subtracted from
underlying colors (blacks appear
transparent)
160
Exclusion
underlying colors are inverted
where layer color is lighter; layer’s
colors are then added to
underlying colors (blacks appear
transparent)
192
Invert
Subtractive
underlying colors are subtracted
from layer’s colors (blacks appear
opaque)
224
Invert Additive
layer’s colors are inverted and are
added to inverse of underlying
colors (blacks appear transparent)
