Tiling Positions are in row major order (rows are filled in order).
For example, the 3x3 arrangement is laid out as follows:
Shutter Control
Chan
Size
Function
Default
Snap
1
1
0
Y
2
2
Shutter X
32767
N
4
2
Shutter Y
32767
N
6
1
Red
0
N
7
1
Green
0
N
8
1
Blue
0
N
9
2
Shutter Scale
65535
N
11
1
Shutter Edge
0
N
12
1
Shutter 1a
0
N
13
1
Shutter 1b
0
N
14
1
Shutter 2a
0
N
15
1
Shutter 2b
0
N
16
1
Shutter 3a
0
N
17
1
Shutter 3b
0
N
18
1
Shutter 4a
0
N
19
1
Shutter 4b
0
N
20
1
Shutter Rotation
127
N
Shutter Shape
Values
Shape
Notes
0-9
Disabled
10-19
Moving
Light Mode
Separate controls for each end of
shutter. If both controls are zero,
shutter disappears.
20-29
Leko Mode
Distance and angle controls. If
distance is zero, shutter disappears.
30-39
Iris Mode
A round iris, scale is magnified to
enclose the screen. No other controls.
40-49
Blob Mode
A Bezier curve is drawn touching the
midpoints of the rectangle formed by
Leko Mode.
Tile Mode
Value
Mode
0
Tiling Disabled
1
2x2 - 1 of 4
2
2x2 - 2 of 4
3
2x2 - 3 of 4
4
2x2 - 4 of 4
5
3x3 - 1 of 9
6
3x3 - 2 of 9
7
3x3 - 3 of 9
8
3x3 - 4 of 9
9
3x3 - 5 of 9
10
3x3 - 6 of 9
11
3x3 - 7 of 9
12
3x3 - 8 of 9
13
3x3 - 9 of 9
14
4x4 - 1 of 16
15
4x4 - 2 of 16
16
4x4 - 3 of 16
...
...
29
4x4 - 16 of 16
