MBOX
®
MEDIA SERVER USER MANUAL
181
Mbox Parameter Descriptions
Fixture
Parameter
Description
Ambient Light
Intensity
The ambient light washes 3D
objects evenly from all sides,
no shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 1
Intensity
Spot 1 washes 3D objects
from top right, casting
shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 2
Intensity
Spot 2 washes 3D objects
from top left, casting shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 3
Intensity
Spot 3 washes 3D objects
from below, casting shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 4
Intensity
Spot 4 washes 3D objects
from above, casting shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Master
Texture
Effect 1
2D effect applied to the final
Modifier 1A
First modifier
Modifier 1B
Second modifier
Texture
Effect 2
2D effect applied to the final
Modifier 2A
First modifier
Modifier 2B
Second modifier
Intensity
Intensity of the video output
from the I/O module (hardware
dimming)
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Orbit X
Moves the camera horizontally
around 3D objects
Orbit Y
Moves the camera vertically
around 3D objects
Dolly
Moves the camera towards
and away from 3D objects
Roll
Rotates the camera on its lens
axis
Spin
Spins the camera on its lens
axis
Field of
View
Adjusts the FOV of the camera
lens
Pitch
Tilts the camera up and down
in relation to 3D objects
Yaw
Angles the camera left and
right in relation to 3D objects
Control
Control functions for server -
HUDs, macros, etc.
Decay
Draws trails behind moving
content
Shutter
Damping
Applies timing to shutter
movement
Pixel Map
Level
Intensity master for pixel
mapping Art-Net output
Control
Selector
Set in combination with the
Master Control channel for
macro selection
Audio
Volume
Level master for audio output
Mbox Parameter Descriptions (Continued)
Fixture
Parameter
Description
