Output Configuration: Single Media Server with Plasma Display and LCD Projector
In the following configuration, a Plasma Display and LCD Projector are connected to a single Mbox Extreme server.
Figure 2-3: Single Media Server with Plasma Display and LCD Projector
VGA IN
PLASMA
DISPLAY
DVI 1 OUT
LCD PROJECTOR
MBOX EXTREME
