Appendix B: Reporting codes
72 NX-6V2 Control Panel Installation Manual
Loc. Description Default Setting
Segment 3
1 = Open/close
2 = Bypass
3 = Restore
4 = Trouble
5 = Tamper
6 = Cancel
7 = Recent closing
8 = Exit error
Segment 4
1 = Late to close/early to open
2 to 8 = Reserved
Segment 5 = Reserved
91 Partition 2 entry and exit times
Segment 1 = Entry time 1 0
Segment 2 = Exit time 1 0
Segment 3 = Entry time 2 0
Segment 3 = Exit time 2 0
Segments 5 and 6 = Reserved
92
to
109 Reserved
110 Zone type 1 alarm event code 8
111 Zone type 1 feature select
Segment 1
1 = Fire (enable f or fire zone)
2 = 24-hour (enable for non-fire 24-hour)
3 = Keysw itch zone
4 = Follow er (enable for burg zones that are instant
during non-entry times)
5 = Delay 1 zone (enable to follow timer 1 entry/exit
times)
6 = Delay 2 zone (enable to follow timer 2 entry/exit
times)
7 = Interior (enable for auto bypass or stay arming
8 = Local only (enable if zone is not to be reported)
Segment 2
1 = Keypad audible on alarm
2 = Yelping siren on alarm
3 = Temporal siren on alarm
4 = Chime
5 = Bypassable
6 = Group shunt
7 = Force armable
8 = Entry guard
Segment 3
1 = Fast loop response
2 = Double end of loop tamper zone
3 = Trouble zone (day zone)
4 = Cross zone
5 = Dialer delay zone
6 = Sw inger zone
7 = Restore reporting
8 = Listen-in
Segment 4
1 = Zone activity monitor
2 = End of line resistor defeat
3 = Zone acts as request to exit input
4 = Zone acts as access entry point (do not enable this
segment option unless configured w ith access control
module)
5 to 8 = Reserved
Segment 5 = Reserved
112 Zone type 2 alarm event code 2
113 Zone type 2 feature select 2, 125, 78, 0, 0
