Appendix B: Reporting codes
68
NX-6V2 Control Panel Installation Manual
Loc. Description
Default
Setting
Segment 4 = Siren time (1 to 254).
8 (minutes)
Segment 5 = Telephone line cut delay (0 to 255)
0 (seconds)
Segment 6 = Cross zone time (0 to 255)
5 (minutes)
Segment 7 = Chime time in 50 mS increments (0 to
255)
3
Segment 8 = Dialer delay (15 to 255)
30 (seconds)
Segment 9 = Fire alarm verification time (120 to 255)
0 (seconds)
Segment 10 = Listen-in time (0 to 255)
0 (seconds)
Segment 11 = Zone monitor timer (0 to 255)
0 (days)
Segments 12 to 14 = Reserved
41
Special features
Segment 1
1 = Enable six-digit code option
2 = Require valid user code entry for *, 9, 8 and * 9, 9
functions to w ork
3 = Enable auto cancel/abort
4 = Enable w alk test mode
5 = Enable auto force-arming w ith keyfob or keysw itch
6 to 8 = Reserved
42
Go to program code
9, 7, 1, 3, 0, 0
43
Go to program code and authorization
Segment 1
1 = Reserved
2 = Enable go to program code as an arm only code
3 = Enable go to program code as an arm only after
closing
4 = Enable go to program code as a master
arm/disarm code (can change user code)
5 = Enable go to program code as an arm/disarm
code
6 = Enable go to program code to bypass zones
7 = Enable go to program code opening and closing
reports
8 = Reserved
Segment 2
1 = Enable go to program code for partition 1
2 = Enable go to program code for partition 2
44
Duress code
15, 15, 15, 15, 15, 15
45
Auxiliary outputs 1 to 4 partition selection
Segment 1 = Output 1 partitions
1
2
Segment 2 = Output 2 partitions
1
2
Segment 3 = Output 3 partitions
1
2
Segment 4 = Output 4 partitions
1
2
46
Auxiliary outputs 1 to 4 special timing
Segments 1 to 4 (outputs 1 to 4)
Output 1
Output 2
Output 3
Output 4
1 = Aux output timed in minutes
1
1
1
1
2 = Aux output to latch
2
2
2
2
