Networx, Product overview, Product contents – Interlogix NX-6V2 Rev C Installation Manual User Manual
Page 6

Chapter 1: Reporting codes
2
NX-6V2 Control Panel Installation Manual
Product overview
The NX-6V2 Control Panel is a residential security and alarm system and
provides the following features:
• Sophisticated software allowing up to 40 users to interface with up to 16
zones and two partitions.
• Integrated fire and input/output modules.
• Fast SIA and Contact ID formats.
• System expansion with up to 16 keypads and three modules. Keypads can
include NX-148E-RF keypads that have built-in wireless receivers.
Figure 1: NX-6V2 Control Panel
9
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
Product contents
The NX-6V2 Control Panel generally comes with:
• One metal enclosure
• One LED keypad
For additional hardware, refer to the Table 3 on page 6.
NetworX
