Chapter 2: Reporting codes
38 NX-6V2 Control Panel Installation Manual
16 = Autotest
a
17 = Alarm memory
18 = Entry 19 = Exit
20 = Entry or exit 21 = Armed state (follows Armed LED)
22 = Disarmed state 23 = Ready
24 = Not ready 25 = Fire (follows Fire LED)
26 = Fire trouble 27 = Chime (chime must be on at keypad)
28 = Expander trouble
a
29 = Dynamic battery test time
30 = Open period 31 = Closed period
32 = Listen in 33 = Line seizure
34 = Ground start (momentary at start of phone
dial) 35 = Fail to communicate
36 = Telephone line fault 37 = Program mode
38 = Download in process (for modem
connection only) 39 = Smoke power
40 = Short circuit (overcurrent panel only) 41 = Box tamper
42 = Siren tamper 43 = Any open
44 = Any short 45 = Any fault (short on nonfire zone)
46 = Any alarm (includes 24-hour zones but not
keypad panics)
a
47 = Beeping keypad
48 = Code entry
a b
49 = Key fob function 1
a c
50 = Key fob function 2
a c
51 = Always on
52 = Alarm flash 53 = Armed away
54 = Armed stay 55 = Aux comm fail (NX-590E, NX-591E)
56 = CP-01 . Progress annunciation (output
toggles slowly during exit delay, then fast during
the last 10 seconds; on steady during entry
delay)
a. These events are 1 second if set to follow condition.
b. When event 48 is programmed, it is possible to program a user code’s authorization to select
which outputs a particular code activates. In *6, user code authority assignment mode, when LED
8 is on for authorization, then LEDs 1 to 2 correspond to that code activating outputs 1 to 2
respectively.
c. Events 49 and 50 require one or more of the following to operate: NX-148E-RF, NX-408E, NX-
448E wireless receivers, NX-548E or NX-1700E/NX-1710E card readers.
Location 51 - Autotest control
Location 51 has four segments of numerical data.
