Appendix A: Reporting codes
62
NX-6V2 Control Panel Installation Manual
Zone ID or user ID hex digit for 4+2 formats
Zone or user ID hex digits only apply to slow formats (Locations 56 to 83, lower
digit). The digits programmed in these locations are sent as the upper hex digit in
place of the alarm event code. The zone ID or user ID are always reported as the
lower hex digits. The following table shows the hex digit for the zone/user IDs.
For example, if the zone/user ID is 15, the 4+2 lower digit is F.
Table 17: Zone/user ID and hex digit
Zone/user ID = Hex digit
Zone/user ID = Hex digit
Zone/ID = Hex digit
1 = 1
2 = 2
3 = 3
4 = 4
5 = 5
6 = 6
7 = 7
8 = 8
9 = 9
10 = A
11 = B
12 = C
13 = D
14 = E
15 = F
16 = 1
17 = 2
18 = 3
19 = 4
20 = 5
21 = 6
22 = 7
23 = 8
24 = 9
25 = A
26 = B
27 = C
28 = D
29 = E
30 = F
31 = 1
32 = 2
33 = 3
34 = 4
35 = 5
36 = 6
37 = 7
38 = 8
39 = 9
40 = A
