Appendix B: Reporting codes
NX-6V2 Control Panel Installation Manual 69
Loc. Description Default Setting
3 = Aux output to stop timing upon user code
entry
3 3 3 3
4 = Aux output activates only betw een closing and
opening time
4 4 4 4
5 = Aux output activates only betw een opening and
closing time
5 5 5 5
6 = Invert aux output (0 V going to 12 V w hen
activated)
6 6 6 6
47 Auxiliary output 1 event/times
Segment 1 = Event number for output 1 0 (burglary alarm)
Segment 2 = Timing for output 1 10 (seconds)
48 Auxiliary output 2 event/times
Segment 1 = Event number for output 2 1 (fire alarm)
Segment 2 = Timing for output 2 10 (seconds)
49 Auxiliary output 3 event/times
Segment 1 = Event number for output 3 2 (24-hour alarm)
Segment 2 = Timing for output 3 10 (seconds)
50 Auxiliary output 4 event/times
Segment 1 = Event number for output 4 39 (smoke pow er)
Segment 2 = Timing for output 4 0 (follow condition)
51 Autotest control
Segment 1 = Autotest interval
0 = Days
1 = Hours
2 = Days and suppresses the test if any report has
been sent w ithin the last interval
3 = Hours and suppresses the test if any report has
been sent w ithin the last interval
1
Segment 2 = Autotest interval from 1 to 255 days or
hours based on Segment 1
24 (hours)
Segment 3 = Hour of the autotest in 24-hour time
format
2 (0200)
Segment 4 = Autotest report time, min. after the hour. 0
52 Opening/automatic disarm times
Segment 1 = Hour of the opening time 8
Segment 2 = Minutes after the opening time 0
53 Closing/automatic arming times
Segment 1 = Hour of the closing/auto arming time 20
