Chapter 2: Reporting codes
NX-6V2 Control Panel Installation Manual
37
Location 48 - Auxiliary output 2 event and times
Location 48 has two segments of numerical data.
Segment 1 - Use Table 8 below to select the event that activates auxiliary output 2. Default is 1
Segment 2 - Program the timing from 0 to 255 (minutes or seconds, depending on data
programmed in Location 46, segment 1). Programming a 0 makes the output follow the event.
Default is 10 (seconds).
Location 49 - Auxiliary output 3 event and times
Location 49 has two segments of numerical data.
Segment 1 - Use Table 8 below to select the event that activates auxiliary output 3. Default is 2
Segment 2 - Program the timing from 0 to 255 (minutes or seconds, depending on data
programmed in Location 46, segment 1). Programming a 0 makes the output follow the event.
Default is 10 (seconds).
Location 50 - Auxiliary output 4 event and times
Location 50 has two segments of numerical data.
Segment 1 - Use Table 8 below to select the event that activates auxiliary output 4. Default is
21.
Segment 2 - Program the timing from 0 to 255 (minutes or seconds, depending on data
programmed in Location 46, segment 1). Programming a 0 makes the output follow the event.
Default is 10 (seconds).
Table 8 below describes the auxiliary output event selections.
Table 8: Auxiliary output events selection
0 = Burglary alarm
a
1 = Fire alarm (includes keypad panic)
a
2 = 24-hour alarm (includes keypad panics and
zone types 2 and 7)
a
3 = Trouble alarm (does not include phone
trouble)
a
4 = Tamper alarm
a
5 = Yelping siren (burglary)
6 = Temporal siren (fire)
7 = Any siren
8 = Any bypass
9 = AC fail
10 = Low battery (does not include expansion
battery)
11 = Duress
a
12 = Aux 1 keypad zone (keypad fire panic)
a
13 = Aux 2 keypad zone (keypad emergency
panic)
a
14 = Panic keypad zone (keypad police panic)
a
15 = Keypad tamper
