Appendix B: Reporting codes
66
NX-6V2 Control Panel Installation Manual
Loc. Description
Default
Setting
23
Partition 1 feature selection
Segment 1
1 = Quick arm
2 = Re-exit
3 = Auto bypass
4 = Silent panic
5 = Audible panic
6 = Auxiliary 1
7 = Auxiliary 2
8 = Multi-keypress tamper
Segment 2
1 = LED extinguish enable
2 = Require user code for bypassing zones
3 = Bypass sounder alert
4 = AC pow er/low battery sounder alert
5 = Enable bypass toggle
6 = Enable silent auto arm
7 = Enable automatic instant
8 = Enable instant mode toggle
Segment 3
1 = Open/close
2 = Bypass
3 = Restore
4 = Trouble
5 = Tamper
6 = Cancel
7 = Recent closing
8 = Exit error
Segment 4
1 = Late to close/early to open
2 = Auto arm in stay mode
3 = Disables door delays in night mode
4 = Bypass disabled for force arm zones
Segment 5 (Reserved)
24
Entry/exit times)
Segment 1 = Entry time 1
30
Segment 2 = Exit time 1
60
Segment 3 = Entry time 2
30
Segment 4 = Exit time 2
60
Segment 5 and 6 = Reserved
25
Zones 1 to 8 zone types
3, 5, 6, 6, 6, 6, 6, 6
26
Zones 1 to 8 partitions
Segment 1 = 1 2
Segment 2 = 1 2
Segment 3 = 1 2
Segment 4 = 1 2
Segment 5 = 1 2
Segment 6 = 1 2
Segment 7 = 1 2
Segment 8 = 1 2
27
Zones 9 to 16 zone types
6, 6, 6, 6, 6, 6, 6, 6
28
Zones 9 to 16 partitions
Segment 1 = 1 2
Segment 2 = 1 2
Segment 3 = 1 2
Segment 4 = 1 2
Segment 5 = 1 2
Segment 6 = 1 2
Segment 7 = 1 2
Segment 8 = 1 2
29
to
36
Reserved
