19
❏
2. Futaba T7CH: Select the [PARAMETER] menu and
verify the model [TYPE>] is set to [H-1]. Position the cursor
on [RESET>EXECUTE]. Press the rotary dial and hold it for
two seconds. The screen will show [SURE?]. Press the
rotary dial again to confirm and execute the reset.
❏
3. Futaba T9CH: Select the [PARAMETER] menu and
verify the model [TYPE>] is set to SWH1. Position the cursor
on [RESET>EXECUTE]. Press the rotary dial and hold it for
two seconds. The screen will show [SURE?]. Press the
rotary dial again to confirm and execute the reset.
SET MODULATION TYPE
6EXH
7CH
9CH
Most computer radios are capable of transmitting in FM/PPM
or PCM. Depending on your radio and receiver, you must set
the modulation type in the radio. If the modulation type is
wrong, the receiver and servos will not operate at all. If you
are having problems, this is the first thing to check.
Once the modulation type is changed, it is necessary to
power down and power up again before the change will take
effect. Futaba radios also keep the modulation type in
memory for each model. If the modulation changes from
model to model, then the transmitter must be powered down
and up again before the controls will work.
❏
Futaba T6EXH: Select the [MODL] menu and press (Select)
button twice.The screen should now show [PULS] [PPM/PCM].
Use the data
and button to select the type.
❏
Futaba T7CH: Select the [PARAMETER] menu and use the
and cursor buttons to scroll down to the [MODUL>]
line. Use the rotary dial to select either [PCM] or [PPM].
❏
Futaba T9CH: Select the [PARAMETER] menu and use
the and buttons to scroll down to the [MODUL] line.
Use the rotary dial to select either [PCM] or [PPM].
MODEL NAME
6EXH
7CH
9CH
❏
Futaba T6EXH: Select the [MODL] menu and press the
(Select) button three times. Use the and data buttons
to change letters and use the (Select) button to move to the
next character.
❏
Futaba T7CH: Select the [MODEL] menu and use the
button to move down to [NAME]. Use the Rotary Dial to
change letters and the and buttons to change
positions within the name.
❏
Futaba T9CH: Select the [MODEL] menu and use the
and buttons to move down to [NAME]. Use the Rotary
Dial to change letters and the and buttons to change
positions within the name.
EXPONENTIAL
Exponential should be used to soften the control feel around
center. Futaba radios use a “–” percentage to soften the
sensitivity. Please read your transmitter’s instruction manual
to determine if “–” or “+” exponential should be used. Futaba
users should start out with –30
% exponential on the
following controls: Forward and Aft cyclic, Left and Right
cyclic, and Tail Rotor.
Most radios allow you to set the exponential for low and high
rates independently; you should set both rates to the same
value in case you accidentally have the dual rate switched
on. Dual rates are not needed on the Kinetic .50. If you still
feel the model is too sensitive, increase the exponential
%
until you are satisfied with the overall feel.
