Heli-Max HMXE07 User Manual
Heli-Max Air equipment
READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION.
IT CONTAINS IMPORTANT INSTRUCTIONS AND WARNINGS
CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.
Champaign, Illinois
(217) 398-8970
INSTRUCTION MANUAL
Rotor Span: 20.75 in [528mm]
Height: 8.125 in [206 mm]
Length: 23 in [584mm]
Weight:16 oz [454g]
Motor: 380 Brushed Motor
Radio: 5-Channel FM with 3 Micro Servos,
Receiver, ESC, and Gyro
• Only use a LiPo approved charger. NEVER use a NiCd/
NiMH peak charger!
• Do not attempt to use this charger with NiCd or NiMH
battery packs.
• Never charge in excess of 4.20V per cell.
• Only charge through the “charge” lead. Never charge
through the “discharge” lead.
• Use only the supplied AC wall adapter to power the charger.
• If the battery should become damaged, discard the battery.
Do not attempt to use a damaged battery.
• Do not leave the charger unattended while charging.
Disconnect the battery and remove input power from the
charger immediately if either becomes hot! However, It is
normal for the charger to get warm.
• Disconnect the battery from the charger and carefully move
the battery to a fi reproof location if the battery begins to
swell or smoke!
• Never charge at currents greater than 1C.
• Always charge in a fi reproof location.
• Never trickle charge.
• Never allow the battery temperature to exceed 150° F
[65° C].
• Never disassemble or modify pack wiring in any way or
puncture cells.
• Never discharge below 2.5V per cell.
• Do not allow water, moisture or foreign objects into
the charger.
• Do not block the air intake holes, which could cause the
charger to overheat.
• Do not place the charger or any battery on a fl ammable
surface or near a combustible material while in use.
• Do not charge on a carpet, cluttered workbench, paper,
plastic, vinyl, leather, wood, and inside an R/C model.
• Never charge inside a full sized vehicle.
• Always disconnect the battery from the charger and the
power supply from the charger when not in use.
• Do not attempt to charge a battery if it is swollen or hot.
• ALWAYS KEEP OUT OF REACH OF CHILDREN.
IMPORTANT PRECAUTIONS
WARNING!! Read the entire instruction sheet included with this battery and charger. Failure to follow all
instructions could cause permanent damage to the battery, charger or its surroundings, and cause bodily harm!
