Heli-Max HMXE09 User Manual
Heli-Max Air equipment
READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION.
IT CONTAINS IMPORTANT INSTRUCTIONS AND WARNINGS
CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.
Champaign, Illinois
(217) 398-8970
INSTRUCTION MANUAL
Rotor Span: 10.6 in [270mm]
Height: 5.9 in [150mm]
Length: 10.8 in [275mm]
Width: 2.5 in [65mm]
Weight: 2.65 oz [75g] no battery
Flying Weight: 4.26 oz [121g] with supplied fl ight battery
•
Only use the included charger with the included battery
or replacement part (GPMP0407).
•
Do not attempt to use this charger with NiCd or NiMH
battery packs.
• Never charge in excess of 4.20V per cell.
•
If the battery should become damaged, discard the
battery. Do not attempt to use a damaged battery.
•
Do not leave the charger unattended while charging.
Disconnect the battery and remove input power from the
charger immediately if either becomes hot! However, it is
normal for the charger to get warm.
•
Disconnect the battery from the charger and carefully
move the battery to a fi reproof location if the battery
begins to swell or smoke!
• Never charge at currents greater than 1C.
• Always charge in a fi reproof location.
• Never trickle charge.
•
Never allow the battery temperature to exceed 150° F
[65° C].
•
Never disassemble or modify pack wiring in any way or
puncture cells.
• Never discharge below 2.5V per cell.
•
Do not allow water, moisture or foreign objects into
the charger.
•
Do not block the air intake holes, which could cause the
charger to overheat.
•
Do not place the charger or any battery on a fl ammable
surface or near a combustible material while in use.
•
Do not charge on a carpet, cluttered workbench, paper,
plastic, vinyl, leather, wood, or inside an R/C model.
• Never charge inside a full-sized vehicle.
•
Always disconnect the battery from the charger and the
power supply from the charger when not in use.
• Do not attempt to charge a battery if it is swollen or hot.
• ALWAYS KEEP OUT OF REACH OF CHILDREN.
IMPORTANT PRECAUTIONS
™
