C-PRO NANO AND MICRO NAV APPLICATION MANUAL

Page 20

tFLo

Flow alarm delay during normal functioning

1

0

240

sec

LEV2

tCoM

Communication alarm delay

10

1

99

sec

LEV2

SET1

Summer condensation high temperature alarm
set point (chiller)

100.0

80.0

115.0

°C

LEV2

Note 1

diF1

Summer condensation high temperature alarm
differential (chiller)

5.0

1.0

15.0

°C

LEV2

Note 1

SET2

Summer evaporation low temperature alarm
set point (chiller)

0.0

-15.0

5.0

°C

LEV2

Note 1

diF2

Summer evaporation low temperature alarm
differential (chiller)

5.0

1.0

15.0

°C

LEV2

Note 1

SET3

Winter evaporation low temperature alarm set
point (heat pump)

-9.0

-15.0

0.0

°C

LEV2

Note 1

diF3

Winter evaporation low temperature alarm
differential (heat pump)

5.0

1.0

15.0

°C

LEV2

Note 1

SET4

Winter condensation high temperature alarm
set point (heat pump)

115.0

90.0

120.0

°C

LEV2

Note 1

diF4

Winter condensation high temperature alarm
differential (heat pump)

5.0

1.0

15.0

°C

LEV2

Note 1

dAL1

Delta 1 : temperature difference AI1 – AI2
that signals alarm (summer chiller)

9.0

0.0

20.0

°C

LEV2

Note 1

EAL1

Enable Delta 1 : temperature value below
which the probe AI1 must be found

20.0

0.0

50.0

°C

LEV2

Note 1

dAL2

Delta 2 : temperature difference AI1 – AI2
that signals alarm (summer chiller)

-2.0

-10.0

0.0

°C

LEV2

Note 1

dAL3

Delta 3 : temperature difference AI2 – AI1
that signals alarm (winter heat pump)

11.0

0.0

20.0

°C

LEV2

Note 1

EAL3

Enable Delta 3 : temperature value above
which the probe AI1 must be found

35.0

0.0

50.0

°C

LEV2

Note 1

dAL4

Delta 4 : temperature difference AI2 – SETH
that signals alarm (winter heat pump)

2.0

0.0

20.0

°C

LEV2

Note 1

tAL4

Delta 4 alarm by-pass time

30

0

999

sec

LEV2

nDeL

Number of interventions/hour of the Delta
alarms so that the alarm becomes manual

1

0

9

LEV2

tDeL

Activation delay time of the Delta alarms from
compressor switch-on

10

0

999

sec

LEV2

dSF

Minimum difference |AI1 – AI2| from
compressor start-up that signals the ASF
Phases Sequence alarm

0.8

0.0

2.0

°C

LEV2

Note 1

tSF

Phases Sequence alarm activation delay time
from compressor start-up

100

0

999

sec

LEV2

ADMINISTRATOR PARAMETERS

nUM

Sets the number of slave units connected to the
master

2

0

4

LEV3

UdM

Sets the temperature unit of measurement:
0: °Celsius
1: °Fahrenheit

0 (°C)

0

1

LEV3

Addr

Board Modbus Address

1

1

247

LEV3

bAud

Baud Rate of the boar communication
(1=2400, 2=4800, 3=9600, 4=19200)

3

1

4

LEV3

Equal

ModBus Parity (0=none, 1=Odd, 2=Even)

2

0

2

LEV3

StoP

StopBit ModBus (0=1bit, 1=2bit)

0

0

1

LEV3

PDI1

Sets the digital input logic used for the flow
switch:
0: Normally open NO

NO

NO (0)

NC (1)

LEV3

NC = flow
OK
