3 dimensions – EVCO EVXS815P9 Installer manual User Manual
Page 52
EVCO S.p.A.
EVSX815 | Installer manual ver. 1.3 | Code 144XS815E134
page 52 of 60
The following table illustrates the meaning of EVIF20TRX parts.
Part
Meaning
1
RS-232 port
2
TTL door on moveable support
3
TTL door on rigid support
4
reserved
5
non-optoisolated RS-232/TTL serial interface EVIF20TRX
6
1256800042 telephone cable
7
port for telephone connector
8
1256800079 adapter
9
RS-232 port
13.3.3
Dimensions
The following drawing illustrates EVPROG01 dimensions; these are expressed in mm (in).
