2.2
Description of the control module
The following drawing illustrates the aspect of the EVXS815 control module.
The following table illustrates the meaning of EVXS815 control module parts.
Part
Meaning
1
serial port with MODBUS communication protocol
2
communication port with the user interface (signal and power supply)
For further information, see the next chapters.
