Spartan-3 Starter Kit Board User Guide www.xilinx.com 53
UG130 (v1.1) May 13, 2005 1-800-255-7778
R
Appendix A
Board Schematics
This appendix provides the schematics for the Spartan-3 Starter Kit Board:
•
Figure A-1 , “A1, A2, and B1 Expansion Connectors”
•
Figure A-2 , “Slide Switches, Push Buttons, LEDs, and Four-Character 7-Segment
Display”
• Figure A-3 , “Voltage Regulators, JP2 Jumper Setting for PS/2 Port Voltage”
• Figure A-4 , “FPGA Configuration Interface, Platform Flash, JTAG Connections,
Jumper JP1”
• Figure A-5 , “FPGA I/O Connections, Clock Sources”
•
Figure A-6 , “Power Decoupling Capacitors”
• Figure A-7 , “RS-232 Serial Port, VGA Port, PS/2 Port, Parallel Cable IV JTAG
Interface”
• Figure A-8 , “2x256Kx16 Fast Asynchronous SRAM Interface”
• Figure A-9 , “Digilent JTAG3 Low-Cost JTAG Download/Debug Cable”
