Chapter 10: Platform Flash Configuration Storage R
Additional FPGA logic is required to read the Platform Flash data, as described in the
following application note.
• XAPP694: Reading User Data from Configuration PROMs
http://www.xilinx.com/bvdocs/appnotes/xapp694.pdf
“Disable” Option
If the JP1 jumper is removed, then the Platform Flash is disabled, potentially allowing
configuration via an expansion board connected to one of the expansion connectors.
